1"Bsp Cs 3Pc Fsas Fbbv F/W Prisma Da Act

Haitima 1"BSP Cs 3PC FSAS Full Bore Ball Valve F/W PRISMA DA Actuator DA 2013KMD-1C

SKU DA 2013KMD-1C
£300.85 - £300.85
£300.85
£300.85 - £300.85
£300.85

1" BSP Parallel, 3 Piece Ball Valve Fitted with a Pneumatic Actuator, Double Acting, ATEX, Fire Safe Approved, Carbon Steel Valve Material, Viton Seal Material, Valve Working Temperature -20°C to +220°C, Actuator Working Temperature -32°C to +80°C, Valve Maximum Working Pressure 138 bar, Prisma, Haitima Features: Stainless steel or carbon steel full bore direct mount ball valve. Available in BSPP, NPT, butt weld nominal bore or socket weld ends. Fire Safe approved and anti-static device (valve only). ATEX II 2G Ex h IIB T6 Gb / II 2D Ex h IIIC T80°C Db certification. Prisma aluminium pneumatic actuator. Sized based on 10 bar pilot air and wet non-abrasive duty at +90°C.
