Haitima Model HTD-140 Double Acting Pneumatic Actuator HTD-140

Double Acting Actuator, 0-90° Rotation Angle, ATEX Approved, Hard Anodized Aluminium, 1.7 Litres per Minute Air Consumption Opening, 2.4 Litres per Minute Air Consumption Closing, 526.44 Torque Nm, Working Temperature -20°C to +90°C, Haitima Features: 0-90° rotation angle to pilot ball, butterfly and plug valves. Double acting torques from 9 to 3916.30Nm at 6 bar. Single acting torques from 4.13 to 1580.40Nm end of spring. Hard anodized aluminium body. ATEX II 2GD c T5 certification. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. Epoxy coated end caps. NAMUR pneumatic connection for solenoid valve installation.
