Haitima 4" PN40 SS FSAS Full Bore Ball Valve F/W Double Acting Actuator HDA 2019D4 12 - FluidAirFittings

Haitima 4" PN40 SS FSAS Full Bore Ball Valve F/W Double Acting Actuator HDA 2019D4 12

SKU HDA 2019D4 12
£2,997.31 - £2,997.31
£2,997.31
£2,997.31 - £2,997.31
£2,997.31

4" PN40 Flange, 2 Way Ball Valve Fitted with a Pneumatic Actuator, Double Acting, ATEX, Fire Safe Approved, Stainless Steel Valve Material, Viton Seal Material, Valve Working Temperature -20°C to +200°C, Actuator Working Temperature -20°C to +90°C, Valve Maximum Working Pressure 40 bar, Haitima Features: Stainless steel or carbon steel full bore direct mount ball valve. PN16 or PN40 flanged ends. PN16/40 up to 2". Fire Safe approved and anti-static device (valve only). ATEX II 2GD c T5 certification. Haitima aluminium pneumatic actuator. Sized based on 10 bar pilot air and wet non-abrasive duty at +90°C.
